System 03
Metal Clad
A laminated hardwood core wrapped in a precision-formed metal shell — aluminum, bronze, or stainless steel — with integrated drainage. Timber warmth inside, zero maintenance outside.
Technical data
| Profile depth | 90–115 mm |
|---|---|
| Core construction | 3-ply laminated, reverse-grain |
| Exterior cladding | Aluminum · Bronze · Stainless Steel |
| Construction | Floating system · extruded profiles · welded miters |
| Drainage | Integrated shell drainage system |
| Interior finish | Hardwood stains · 1,500+ RAL / NCS |
| Operations | Tilt-turn · casement · fixed · lift-slide · folding · entry · pivot |
| Hardware | Multi-point locking, salt-air rated |
| Certification | NAMI certified |
| Warranty | 10-year full, transferable |
Performance
Thermal0.12–0.16Uw-value installed, triple glaze · R-8 to R-10 equivalent
Acoustic34–50 dBStandard to enhanced glazing
Structural · CoastalDP 65+140 mph sustained wind · Large Missile Impact Level D · corrosion-protected shell
Detail
Three exterior metals. One warm interior.
AluminumThe eco-friendly, lightweight default — suited to most exposures.
BronzeA living finish for oceanfront and high-corrosion settings.
StainlessMaximum corrosion resistance where the salt air is relentless.
Best for
Coastal & corrosion exposureModern architectureZero-maintenance exteriorsMixed-material facades
Downloads
Specify with confidence.
Public
Metal Clad spec sheet
Full technical data, operations, and certifications. No registration required.
Trade
CAD details & BIM objects
Editable details and BIM families for specification and documentation.
