System 01
uPVC
Five-chamber, steel-reinforced profiles in 100% virgin uPVC. The maintenance-free system — with 50+ woodgrain laminations and thermal numbers that hold their own against timber.
Technical data
| Profile depth | 70 mm |
|---|---|
| Construction | 5-chamber, steel-reinforced |
| Material | 100% virgin uPVC |
| Reinforcement | Full steel frame |
| Finishes | 50+ woodgrain laminations |
| Dual color | Interior / exterior independent |
| Operations | Tilt-turn · casement · fixed · lift-slide |
| Standard glazing | Ug 0.19 · Uw < 0.23 |
| Triple glazing | Argon-filled · Ug 0.11 · Uw < 0.14 |
| Hardware & locking | Multi-point · stainless steel locking points |
| Certification | NAMI — NI011127 · NI011128 · NI010029 |
| Warranty | 10-year full, transferable |
Performance
ThermalR-9Triple argon glazing · Uw < 0.14 installed · ‘warm edge’ spacer against cold bridging
Acoustic34–50 dBStandard to enhanced glazing
Structural · CoastalDP 65+140 mph sustained wind · Large Missile Impact Level D
Detail
Built to resist force, not just weather.
ESP reinforcementFitting bolts screw into hard PVC, steel, and a further hard-PVC strip that runs as a spine through the entire frame and casement.
Counter-movement lockingAny attempt to lever the window — from any direction — meets an opposing force that stops it.
SafeGA glazingTransparent, tear-resistant impact lamination, paired with lockable security handles.
Best for
Large-format openingsCoastal & hurricane zonesLow-maintenance specsNew constructionMulti-family
Downloads
Specify with confidence.
| Revit — uPVC operable window (.rfa) | Download |
|---|---|
| Revit — uPVC fixed window (.rfa) | Download |
| CAD — uPVC standard details base (.dwg) | Download |
| Swing doors — example details (PDF) | Download |
| Specification overview | Download PDF |
Browse the full resource library → Free to download — no registration.
